Bomber Z1 Coil

Regular price $1,049.00

Unit price per


Wheel Size & Colour

Travel

Rake

Chassis: 36 mm
Travel: 150 (29 only), 160, 170, 180 (27.5 only)
Wheel: 27.5 or 29
Axle: 15QRx110
Damping: GRIP (compression + rebound)
Spring: Tempered Silicon-Chromium Steel
Steerer: 1.5 Tapered Aluminum
Stanchions: Ø36 mm Black Anodized
Rake: 37 (27.5 only), 44, 51 (29 only)
Color: Matte Black or Gloss Red
Starting Weight Complete Fork: 2,525 g

Warranty: At Marzocchi, we take pride in the products we build and care about your product working the way that we designed them to work.
If you’ve purchased a Marzocchi product we’ll do our best to find you a solution through our warranty program. Our warranty policy covers all manufacturing defects for the original owner. Marzocchi products are designed and engineered to withstand some of the harshest riding conditions. That being said, these products have a lifetime and will deteriorate over time and may require service to maximize its performance and functionality. Your Marzocchi Warranty Technician will evaluate the failed product and consider factors such as age, riding hours, intended use of product and use environment when determining a warranty claim. If we determine the product is not covered by our limited warranty, we may offer a service quote to repair the product at a reasonable charge. For full warranty information, please click here.

Z1 Coil Configuration Guide

Marzocchi Fork Owners Guide

Riders have been asking for it, Marzocchi heard the call and has proudly delivered. The new Z1 Coil builds on the legacy of the single crown fork that started the revolution way back in the ‘90s – the O.G. Bomber Z1 Coil. Starting with the stout and proven 36mm chassis of the modern day Bomber Z1, the new Z1 Coil retains the renowned Grip damper but swaps out the air spring assembly for the most advanced coil spring system Marzocchi has ever made. At the heart of this new coil system is an ultra-lightweight tempered silicon-chromium steel spring (available in 4 spring rates to suit a wide range of riders) coupled with a noise management system for near silent performance, an integrated air assist for progressivity and bottom out control, and an external preload adjuster to dial in sag and firmness off the top. Travel can easily be changed in 10mm increments from 150-180mm (depending on wheel size) via included reconfigurable internal spacers.


Note the Z1 Coil comes with a medium coil installed. Different configurations must be purchased separately.

Riders have been asking for it, Marzocchi heard the call and has proudly delivered. The new Z1 Coil builds on the legacy of the single crown fork that started the revolution way back in the ‘90s – the O.G. Bomber Z1 Coil. Starting with the stout and proven 36mm chassis of the modern day Bomber Z1, the new Z1 Coil retains the renowned Grip damper but swaps out the air spring assembly for the most advanced coil spring system Marzocchi has ever made. At the heart of this new coil system is an ultra-lightweight tempered silicon-chromium steel spring (available in 4 spring rates to suit a wide range of riders) coupled with a noise management system for near silent performance, an integrated air assist for progressivity and bottom out control, and an external preload adjuster to dial in sag and firmness off the top. Travel can easily be changed in 10mm increments from 150-180mm (depending on wheel size) via included reconfigurable internal spacers.


Note the Z1 Coil comes with a medium coil installed. Different configurations must be purchased separately.

Bomber Z1 Coil

Undeniably Smooth

Finally a buttery smooth coil fork with nothing to prove. No crazy maintenance schedule no downtime. Just get on and go.

I’ve always loved the buttery, effortless feel of a coil fork, and the new Z1 is by far the most buttery fork I’ve ever ridden!

Cam McCaul
